Pump MV 110, PP, EPDM, B

Centrifugal horizontal pump MV 110, PP, EPDM, B

MB 110 Horizontal Chemical Pump

Chemical pumping centrifugal pump MB 110

• Capacity – up to 20 m3/h
• The diameter of the solid particles is up to 2 mm.
• Versions: PP – PVDF

The main features of the MB 110 chemical pump

•  the capacity of the centrifugal pump is up to 20 m3/h
•  without welded joints;
•  pumping liquids containing solid and insoluble particles up to 2 mm in size.
•  pumping of viscous liquids up to 500 Sdr
•  mechanical cuff or bellows seals;
•  use with particularly contaminated liquids (TS seal);
•  ease of maintenance and replacement of components
•  low cost of spare parts

 Technical characteristics of the pump

• Connection of the fence G 2” m
• Reset connection G 1 1/2” m
• Max. capacity 20 m3/h
