MB 155 Horizontal Type Chemical Centrifugal Pump

• Max. capacity – up to 45 m3/h
• The diameter of the solid particles is up to 3 mm.
• Construction materials: PP – PVDF

The main features of the MB 155 centrifugal pump

•  the capacity of the centrifugal pump is up to 45 m3/h
•  the pump is made of polymer, without welded joints
•  pumping liquids containing solid and insoluble particles up to 3 mm in size.
•  pumping of viscous liquids up to 500 Sdr
•  mechanical bellows or lip seals
•  The pump can be used with particularly contaminated liquids
• (when the pump is configured with a bellows seal TS)
•  ease of maintenance and replacement of components
•  low cost of spare parts

Technical characteristics of the pump

• Fence connection G 2 1/2” f
• Sub-
