Main application areas
- Water supply
- Equipment for buildings
- Pressure increase, fire extinguishing installations
Overview of technical data
| Q (50Hz) | 0.0 – 110.0 (m³/h) |
| H (50Hz) | 0.0 – 160.0 (m) |
| Drive motor frequency | 50 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Type of coupling | 00 |
| Type of lubricant | lubrication of the pumped medium |
| Max. number of pumps | 2 |
| Installation of the unit | "dry" installation |
| Housing material (according to EN standard) | 1.4301 |
| Installation position | vertical |
| Main application areas | Industry and technological processes, Water supply, Building engineering equipment |
| Housing material | chrome nickel steel |
| Max. working pressure from the pressure sides | 16 (bar) |
| Max. drive power | 22 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 2900 (1/min) |
| Backup pump | yes |
| Connection type | direct |
Features
Brand
KSB
