THE FILTER IS REGULATED. LFR-1/4-D-MINI
| Characteristic | Meaning |
|---|---|
| Delivery Date + Price |  View |
| Size | Mini |
| Series | D |
| Drive lock | Rotary handle with locking |
| Assembly position | Vertically +/- 5° |
| Degree of filtration | 40 µm |
| Condensate drainage | Manual rotation |
| Type of construction | Filter regulator with pressure gauge |
| Max. condensate volume | 22 cm3 |
| Cup cover | Metal cup casing |
| Pressure gauge | with a pressure gauge |
| Operating pressure | 1 ... 16 bar |
| Control pressure range | 0,5 ... 12 bar |
| Max. pressure hysteresis | 0,2 bar |
| Standard nominal flow rate | 1.400 l/min |
| Marine classification | see the certificate |
| Working environment | Compressed air according to ISO 8573-1:2010 [-:9:-] Inert gases |
| A note on the work environment | It is possible to work with grease (constant lubrication is required afterwards) |
| Classification of corrosion resistance CRC | 2 - Average corrosion resistance |
| Storage temperature | -10 ... 60 °C |
| The purity of the outlet air | Compressed air in accordance with ISO8573-1:2010 [7:8:4] Inert gases |
| Ambient temperature | -10 ... 60 °C |
| Ambient temperature | -10 ... 60 °C |
Features
Brand
Festo
