Main application areas
- Raw water
- Water
- Water disposal
- Water treatment
- Water supply
- Pumps used as turbines
- Disinfection
- Desalination of seawater
- Equipment for buildings
- Irrigation
- Sprinkling irrigation, irrigation
- Cooling water and condensate
- Pressure increase
- Industry and technological process
- Industrial power plants
- Water distribution
- System solutions, rehabilitation
- Water transportation
- Chemistry
- Public power plants
- Energy industry
Overview of technical data
| Q (50Hz) | 4.0 – 1500.0 (m³/h) |
| H (50Hz) | 20.0 – 1000.0 (m) |
| Type of bearing | rolling bearing and sliding underpin |
| Separation of the body | transverse (radial) |
| Drive motor frequency | 50 Hz /60 Hz |
| Type of drive | electric motor, turbine , internal combustion engine |
| Drive motor voltage | low voltage |
| 1. type of impeller | closed /radial |
| Number of impeller inputs | single-threaded |
| Impeller material (according to E standard | 1.4408, CC480K-GS, GJL 250 |
| Type of installation | base plate |
| Type of coupling | directly |
| Type of lubricant | grease/oil lubrication/lubrication of the pumped fluid |
| Pressure housing material (according to the standard | 1.4317, 1.4408, GJL 250, GJS 400, GP240GH+N |
| Max. permissible liquid temperature | 200 (°C) |
| The position of the nozzle | variable |
| Maximum operating pressure | PN 16, 25, 40, 63, 80, 100 |
| Installation of the unit | "dry" installation |
| The material of the stage body (according to the E standard | 1.4317, 1.4404, 1.4408, GJL 250, GJS 400, GP240GH+N, S355J2H |
| The material of the suction body (according to the standard | 1.4317, 1.4404, 1.4408, GJL 250, GJS 400, GP240GH+N |
| Type of connection | the flange |
| Type of pressure housing | housing with an annular camera |
| Type of stage housing | stage body with guide device |
| Type of suction housing | housing with an annular camera |
| Housing material (according to EN standard) | 1.4317, 1.4408, GJL 250, GJS 400, GP240GH+N, S355J2H |
| Installation position | horizontal |
| Type of shaft seal | stuffing box, mechanical seal |
| Main application areas | Industry and technological processes, Water supply, Building engineering equipment |
| Housing material | grey cast iron, steel casting, stainless steel casting, cast iron with spherical graphite |
| Max. working pressure from the pressure sides | 100 (bar) |
| Max. drive power | 1500 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 4000 (1/min) |
Features
Brand
KSB
