High accuracy and reliability for use at critical measuring points. . Compliance with NAMUR NE21, NE43 recommendations. The possibility of use in hazardous areas due to the Ex ia design. Convenient and easy setup, visualization and maintenance via software installed on a PC.
Specifications:
Measurement principle Built-in converter Input 1 x Thermistor, thermocouple, ohms, MV
Output signals 1 x Analog 4...20 mA
Power supply voltage 8...35 V DC (standard version)
8...30 V DC (Explosion-proof version)
The protocol is programmable via a PC
Installation of the mold in
The error is(Pt 100, -50...200°C) <= 0,2 K
Galvanic isolation
Explosion Protection Technology Ex ia
ATEX II3D
ATEX nA
FM USA IS, NI
CSA IS, NI
UL Ex IS, NI
GL Marine Certificate
NEPSI Ex nA
NEPSI Ex ia
GOST Ex i
