BOXER 502 ALU Pump

BOXER 502 ALU Diaphragm Pump

High Performance Diaphragm Chemical Pump BOXER 502

• Max. capacity – up to 650 l/min
• Connections (intake/discharge) – 2” f or DN 50
• Pump versions: PP – PVDF – ALU – AISI 316

The main features of the BOXER 502 chemical pump

•  high pump capacity up to 650 l/min
•  self-pumping of liquid up to 4 m.
•  non-pressure operation mode
•  pumping liquids containing solids and insoluble
• particles up to 8 mm in size.
•  pumping of very viscous liquids
•  performance adjustment from 0 to 100% occurs
• by adjusting the air flow
•  support for the operation of the pump in the "dry running" mode
•  the possibility of dual or independent collectors
• intake and discharge
•  performing the functions of a barrel pump
•  fire safety of the pump design without electric drive
•  standard
