BOXER 80 AISI 316 diaphragm pump

BOXER 80 AISI 316 diaphragm pump

BOXER 80 Pneumatic Diaphragm Pump

• Pump capacity – up to 90 l/min
• Connections – 1 ”
• Versions: AISI 316

The main features of the BOXER 80 diaphragm pump

•  capacity up to 90 l/min
•  self-pumping of liquid up to 5 m.
•  operation in non-pressurized mode
•  pumping liquids containing solid and insoluble particles up to 4 mm in size.
•  pumping of very viscous liquids
•  smooth 0-100% performance adjustment by adjusting the air flow rate
•  support for operation in the "dry running" mode
•  operation mode of dual (independent) intake and discharge collectors
•  the possibility of working on the principle of a barrel pump
•  fire safety of the pump design without electric drive
•  the ability to operate in explosive atmospheres - ATEX II 2/2GD c IIB T 135°C (zone 1) certification
•  standard executed
