BOXER pump 81 PP

BOXER 81 PP IB81-P-MTAAD Diaphragm Pump--

BOXER 81 Diaphragm air pump

• Max. capacity – up to 100 l/min
• Connections – 1 ”
• Versions: PP – PVDF – ALU

The main features of the BOXER 81 diaphragm pump

•  pump capacity up to 100 l/min
•  self-pumping of liquid up to 6 m.
•  the possibility of non-pressurized operation
•  pumping liquids containing insoluble particles up to 4 mm in size.
•  working with viscous liquids
•  0-100% pump capacity adjustment by changing the air flow rate
•  support for operation in the "dry running" mode
•  operation mode of dual (independent) intake and discharge collectors
•  performing the functions of a barrel pump
•  fire safety of the pump design without electric drive
•  стандартное исполнение - сертификация ATEX II 3/3G D IIB T 135°C (zone 2)
•  the possibility of operation in explosive environments
