MINIBOXER AISI pump

MINIBOXER AISI Diaphragm Pump

MINIBOXER Pneumatic Diaphragm Pump

• Capacity – up to 50 l/min
• Connections – 1/2”
• Versions: AISI 316

The main features of the MINIBOXER pump

•  pump capacity up to 50 l/min
•  self-pumping of liquid up to 5 m.
•  the ability to operate the pump in non-pressurized mode
•  pumping liquids containing solid and insoluble particles up to 3 mm in size.
•  pumping of very viscous liquids
•  performance adjustment from 0 to 100% by adjusting the air flow
•  support for operation in the "dry running" mode
•  operation mode of dual (independent) intake and discharge collectors
•  performing the functions of a barrel pump
•  fire safety of the pump design without electric drive
•  стандартное исполнение - сертификация ATEX II 3/3G D IIB T 135°C (zone 2)
•  the possibility of operation in explosive atmospheres - ser
