Main application areas
- Biogas
- Bio-purification /2.degree of purification
- Fur. cleaning /1.degree of cleaning
- Treatment plants
- Waste water
- It's been improved. processing/3.step. cleaning
Overview of technical data
| Q (50Hz) | 10.0 – 830.0 (m³/h) |
| H (50Hz) | 2.0 – 80.0 (m) |
| Type of bearing | rolling bearing |
| Separation of the body | transverse (radial) |
| Drive motor frequency | 50 Hz /60 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Number of impeller inputs | single-threaded |
| Impeller material (according to E standard | JL 1040, 1.4517, JN 3029 |
| Type of installation | block |
| Type of coupling | without |
| Type of lubricant | grease |
| Max. permissible liquid temperature | 70 (°C) |
| The position of the nozzle | mechanical suction |
| Maximum operating pressure | PN16 |
| Process execution | yes |
| Installation of the unit | "dry" installation |
| Shaft material (according to EN standard) | 1.4462, 1.4021 |
| Suction characteristics | non-self-priming |
| Housing type | spiral body |
| Type of impeller | open, multi-channel impeller, free-vortex impeller, closed, radial |
| Type of connection | the flange |
| Housing material (according to EN standard) | JL 1040 |
| eClass | 36410101, 36410103 |
| Max. free passage | 120 (mm) |
| Installation position | horizontal or vertical |
| Type of shaft seal | mechanical seal |
| Main application areas | wastewater, Industry and technological processes |
| Housing material | grey cast iron |
| Max. working pressure from the pressure sides | 10 (bar) |
| Max. drive power | 37 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 1750 (1/min) |
Features
Brand
KSB
