Conical motor reducer BK5055VLA/DPE13XA4
Conical Motor Reducer Type : BK5055VLA/DPE13XA4 Engine power (kW) : 7.5S1
Installation : H1
Drive shaft speed (r/min) : 151.0 Terminal box direction : II/A
Torque (Nm) : 425.0 CAD Drawing : BK50BK50Z CT
fB operation : 2.2 Catalog : P7177BGM
Corrosion protection : Standard Net weight (basic assembly), 1 piece [1] (kg): ca. 147
Painting : RAL 7031 Construction/execution : CE (Standard)
Gearbox design
Type : Conical BK50
Execution code 55VL : torque lever from front to left
: hollow shaft for coupling coupling on the rear side of the gearbox
: with a breather installed
Gear ratio : 9.73
Additional /special design Coupling cover
the motor reducer
complete with coupling (RfN 4161 068x115)
Rubber buffers for the torque lever
Engine design
Type : DPE13XA4 Three-phase electric motor
Voltage/Connection : 400 V D
Frequency (Hz) : 50 Rated speed (r/min) : 1460
Rated current (A) : 15 IP protection class according to with EN 60529 : IP65
Коэффициент мощности (cos phi) : 0.81 охлаждение EN 600346 : IC 411 IECode acc. to EN6003430 : IE390,4%
Insulation class : F Construction in accordance with DIN VDE 05301/EN 600341
Operating mode : S1 Terminal box : TB322
