Metering plunger pump Fimars 50hz NEO

NEO Plunger Pump

Productivity:

• Consumption: 0-425 l/h
• Pressure: up to 150 bar
• Accuracy: ± 2% of the nominal flow rate from 10 to 100% of the nominal flow rate *

Features:

• Low flow rate, high pressure
• Robust, compact, reliable design
• Accurate dosage at any pressure

Adjustment:

• 0-100% stroke adjustment during operation
• Standard micrometric manual adjustment of 1mm
• Optional electric drive, 4-20 mA or 0-10 commands with manual control
• Additional motor with built-in frequency converter

Materials:

• Painted in a silver aluminum case
• Standard housings: S.C. 316 L, PVC
• Individual versions: INCOLOY 825, Hastelloy C276, titanium, etc...
