Characteristic Meaning
Delivery Date + Price View
Motion 10 mm
Piston diameter 63 mm
Return spring force, retraction 50 N
Based on the standard ISO 6431
The shape of the hole
VDMA 24562
Dampening P: non-adjustable damping, elastic rings on both sides
Assembly position Any
Operating mode unilateral action
push action
Type of construction The piston
Stock
Determining the position Without
Operating pressure 1 ... 10 bar
Working environment Compressed air in accordance with ISO8573-1:2010 [7:4:4]
A note on the work environment It is possible to work with grease (constant lubrication is required afterwards)
Classification of corrosion resistance CRC 1 - Low corrosion resistance
Ambient temperature -20 ... 80 °C
Theoretical force at 0.6 MPa (6 bar, 87 psi), advance 1.799 N
Moving mass 157 g
Product Weight 442 g
Mounting type with a through hole
with accessories
Option
Pneumatic connection G1/8
Notes on the material It does not contain copper and Teflon
Cover material Aluminum Alloy
Anodized
Seal material NBR
TPE-U(PU)
Housing material Aluminum Alloy
Anodized
Stock Material Alloy steel
