Main application areas
- Polluted water
- Surface reversal
- General methods
- Treatment plants
- Food products
- Industry and technological process
Overview of technical data
| Q (50Hz) | 0.0 – 40.0 (m³/h) |
| H (50Hz) | 1.3 – 16.0 (m) |
| Type of bearing | ball bearing |
| Cutting device | yes |
| Drive | electric motor |
| Drive motor frequency | 50 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Electrical connector | 400 V, 3~ |
| Explosion protection | WITHOUT |
| Number of impeller inputs | single-threaded |
| Impeller material (according to E standard | JL1030 |
| Type of coupling | without |
| Type of lubricant | lubrication of the pumped medium |
| Max. permissible liquid temperature | 40 (°C) |
| Installation of the unit | "wet" installation |
| Shaft material (according to EN standard) | 1.4021 |
| Suction characteristics | non-self-priming |
| Acceptable for drinking water | yes |
| Housing type | housing with an annular camera |
| Type of impeller | free-swirl impeller, impeller with cutting device |
| Type of connection | the flange |
| UNSPSC classification | 4015150300 |
| Housing material (according to EN standard) | JL1030 |
| eClass | 36410101, 36410000, 36410100 |
| Max. free passage | 60 (mm) |
| Installation position | vertical |
| Type of shaft seal | mechanical seal, shaft O-ring |
| Main application areas | Water supply, wastewater, Building engineering equipment |
| Housing material | grey cast iron |
| Max. drive power | 1,50 (kW) |
| Type of installation | portable, stationary |
| Max. rotation speed | 2900 (1/min) |
Features
Brand
KSB
