Main application areas
- Water
- Water intake
- Mining
- Urban wastewater
- Wells, mines
- Flood control measures, sanitation
Overview of technical data
| Q (50Hz) | 500.0 – 21600.0 (m³/h) |
| H (50Hz) | 2.5 – 55.0 (m) |
| Type of bearing | rolling bearing |
| Separation of the body | transverse (radial) |
| Type of impeller material (according to the standard | 1.4057, 1.4021 |
| Drive | electric motor |
| Drive motor frequency | 50 Hz /60 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Electrical connector | 400/690 V, 3~ |
| Number of impeller inputs | single-threaded |
| Impeller material (according to E standard | CC480K-GS, CC333G-GS |
| Type of installation | execution of the "in-line" type |
| Type of coupling | without |
| Type of lubricant | grease |
| Max. permissible liquid temperature | 40 (°C) |
| The position of the nozzle | execution of the "in-line" type |
| Installation of the unit | "wet" installation |
| Shaft material (according to EN standard) | 1.4021, 1.4057 |
| Suction characteristics | non-self-priming |
| Acceptable for drinking water | yes |
| Type of impeller | diagonal impeller |
| Housing material (according to EN standard) | JL 1040 |
| eClass | 36410000, 36410106, 36410100 |
| Max. free passage | 160 (mm) |
| Installation position | vertical |
| Type of shaft seal | mechanical seal |
| Main application areas | 00, Water, Energy, Mining /Dredging operation |
| Housing material | grey cast iron |
| Max. drive power | 1100 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 1800 (1/min) |
Features
Brand
KSB
