Main application areas
- Water
- Petrochemical industry
- Oil /Gas
- Industry and technological process
- Water distribution
- Water transportation
Overview of technical data
| Q (50Hz) | 0.7 – 320.0 (m³/h) |
| H (50Hz) | 3.5 – 95.0 (m) |
| Type of bearing | rolling bearing |
| Separation of the body | transverse (radial) |
| Drive | electric motor |
| Drive motor frequency | 50 Hz /60 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Electrical connector | 230/400 V, 3~ |
| Explosion protection | ATEX (94/9/EC) |
| 1. type of impeller | single-threaded |
| Max. diving depth | 1585 (mm) |
| Impeller material (according to E standard | CA6NM, CF8M, JL 1040 |
| Type of coupling | directly |
| Type of lubricant | grease/oil lubrication |
| Max. permissible liquid temperature | 100 (°C) |
| Installation of the unit | "dry" installations, flooded |
| Shaft material (according to EN standard) | AISI-316L, F-114 |
| Suction characteristics | non-self-priming |
| Third plate | yes |
| Housing type | spiral body |
| Type of impeller | open |
| Housing material (according to EN standard) | CA6NM, CF8M, JL1040 |
| Installation position | vertical |
| Type of shaft seal | shaft sealing ring |
| Main application areas | Industry and technological processes, Water supply |
| Max. working pressure from the pressure sides | 10 (bar) |
| Max. drive power | 184 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 3500 (1/min) |
Features
Brand
KSB
