Eurotherm Altivar 12 AC drives

Ultra-compact frequency converters of the series Altivar 12 from the company Eurotherm They are a versatile and effective offer for operation as part of drive systems with asynchronous motors with a power of up to 4 kW. To create them, only high-quality materials and electronics are used to ensure maximum reliability and durability in operation. In addition, they are very easy to set up and manage, and the intuitive interface has very convenient functionality for configuring equipment.

Extensive features in the Plug&Play technology format save time and installation and adaptation costs when integrating and configuring the device. There are three different methods available for management, depending on the requirements of the work. Well-established braking and acceleration processes, protective algorithms to ensure safety, built-in EMC filter. The ideal solution for equipping simple applications in the food industry, functioning as part of small-scale mechanization systems, pumping equipment, medical devices, etc.

Technical characteristics of Eurotherm frequency converters of the ATV12 series

• Supply voltage:1AC 100-220V, 200-240V, 3AC 200-240V (50 /60Hz);
• Electric motor power:0.18 - 4 kW;
• Management methods: scalar (U/f), sensorless vector (open contour), quadratic;
• Output frequency: 0.5 - 400 Hz;
• Permissible overloads: 150 - 170 % of the nom. The moment;
• Enclosure protection class: IP20;
• Built-in interfaces: Modbus;
• Visualization and customization tools: graphical control terminal, multi configuration loader, SoMove software, remote terminal (optional);
• Built-in functions: setting the operating speed range, up to 8 presets for speeds, a PID controller, 11 additional functions for controlling pumps, setting the time and profile for acceleration and braking, switching control, driving directions, automatic restart, protective algorithms and other.

Configuration of the inputs/outputs of the Altivar 12 series

• Analog: 1 input, 1 output;
• Digital: 4 inputs, 1 output;
• relay: 1 exit.

Optional drive modules of the Altivar 12 series

• Brake module (including resistor, chokes, filters).

Parameters of standard sizes of Eurotherm ATV12 electric drives

Buy Altivar 12 series frequency converters (ATV12) manufactured Eurotherm You can find out the price and more information about the products by contacting our specialists.
