Maximum flexibility in use is realized in the SIEIDrive ADV100 series of frequency converters from GEFRAN, which covers the power range of driven motors up to 90 kW. The ease of operation is perfectly combined with the advanced control capabilities of asynchronous motors, three different control methods can be used (scalar, vector feedback and vector sensorless).
Maximum energy efficiency, multitasking and a practical modular construction system. Thanks to this design, you can easily and cost-effectively optimize the product by expanding its functionality to the required level from a rich line of components of this brand.
Technical characteristics of the Gefran ADV100 electric drive
- Electric motor power: from 4 to 90 kW;
- Supply voltage: 230 V (-15%) .... 500 V (+5%), 3 phases;
- Overload capacity: 150% for 60 seconds every 5 minutes, 180% for 0.5 seconds every 5 minutes;
- Output frequency range: up to 500 Hz;
- Management method: scalar, vector feedback and sensorless;
- Industrial interface: RS232 (Modbus RTU or Jbus protocol);
- User-friendly interface (keyboard, screen and LED status alarm);
- Operating temperature range: -10 ... 40 °C;
- Protection class IP20;
- Built-in functions: auto-tuning with 2 modes (fast start and max. effective), energy saving function, electromechanical motor brake control, PID control, electromagnetic interference filter, chokes,
Configuration of inputs/outputs of the Gefran ADV100 electric drive
- 2 analog inputs (± 10 V);
- 2 analog outputs;
- 6 digital inputs;
- 2 relay outputs;
- CANopen/DeviceNet port and SD-Card (marking models -C).
Optional Gefran ADV100 electric drive modules
Control panel, LCD display.The switching expansion board.
An external EMC filter.
Braking resistors.
CANopen /DeviceNet module
Input and output choke.
An incremental feedback card with a digital encoder .
Rated characteristics of the Gefran ADV100 electric drive
Type of drive | Power, kW | Voltage |
ADV100-1040 | 4 | 230-500 V, 3 phase |
ADV100-1055 | 5,5 | |
ADV100-2075 | 7,5 | |
ADV100-2110 | 11 | |
ADV100-3150 | 15 | |
ADV100-3185 | 18,5 | |
ADV100-3220 | 22 | |
ADV100-4300 | 30 | |
ADV100-4370 | 37 | |
ADV100-4450 | 45 | |
ADV100-5550 | 55 | |
ADV100-5750 | 75 | |
ADV100-5900 | 90 |
You can buy Gefran ADV100 AC frequency converters, find out the price and more information about the product by contacting our specialists.
