Main application areas
- Drainage
- Drainage pumping stations
- Polluted water
- Dewatering by pressing
- Equipment for buildings
- Waste water
- Transportation of wastewater
- Installations for lifting drains
- Installations for lifting polluted waters
- water disposal
Overview of technical data
| Q (50Hz) | 0.0 – 1000.0 (m³/h) |
| H (50Hz) | 0.0 – 55.0 (m) |
| Type of bearing | ball bearing |
| Drive | electric motor |
| Drive motor frequency | 50 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Electrical connector | 230 V, 1~ |
| Type of coupling | without |
| Type of lubricant | grease |
| Max. permissible liquid temperature | 60 (°C) |
| Max. number of pumps | 3 |
| Installation of the unit | "dry" installations, flooded |
| Suction characteristics | self-priming |
| Type of connection | thread, flange |
| UNSPSC classification | 4015150300 |
| Housing material (according to EN standard) | On |
| eClass | 36410101 |
| Max. free passage | 110 (mm) |
| Installation position | vertical |
| Type of shaft seal | shaft O-ring, mechanical seal |
| Main application areas | Industry and technological processes, Water supply, wastewater, Building engineering equipment |
| Housing material | glass fiber reinforced polyester |
| Type of installation | stationary |
| Max. number of pumps | 3 |
| Max. rotation speed | 2900 (1/min) |
