Main application areas
- Water
- Water disposal
- Water treatment
- Desalination of seawater
- Sprinkling irrigation, irrigation
- Food products
- Industry and technological process
- Industrial power plants
- System solutions, rehabilitation
- Special technologies
- Heat carriers, cooling circuits
- Types of orders
- Water transportation
- Chemistry
- Energy industry
Overview of technical data
| Q (50Hz) | 0.0 – 190.0 (m³/h) |
| H (50Hz) | 0.0 – 401.0 (m) |
| Type of bearing | slide underpin |
| Drive motor frequency | 50 Hz /60 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Impeller material (according to E standard | 1.4301, 1.4404 |
| Type of installation | execution of the "in-line" type |
| Type of coupling | directly |
| Type of lubricant | lubrication of the pumped medium |
| Max. permissible liquid temperature | 140 (°C) |
| The position of the nozzle | execution of the "in-line" type |
| Installation of the unit | "dry" installation |
| Suction characteristics | non-self-priming |
| Acceptable for drinking water | yes |
| Type of connection | the flange |
| UNSPSC classification | 4015150300 |
| Housing material (according to EN standard) | 1.4301, 1.4401, JL1040 |
| eClass | 36410101 |
| Installation position | vertical |
| Main application areas | Industry and technological processes, wastewater, Building engineering equipment |
| Housing material | chrome nickel steel |
| Max. working pressure from the pressure sides | 40 (bar) |
| Max. rotation speed | 2900 (1/min) |
Features
Brand
KSB
