Main application areas
- Pressure increase, fire extinguishing installations
Overview of technical data
| Q (50Hz) | 0.0 – 70.0 (m³/h) |
| H (50Hz) | 0.0 – 110.0 (m) |
| Type of coupling | directly |
| Installation of the unit | "dry" installation |
| Housing material (according to EN standard) | 1.4301 |
| Max. inlet pressure | 6 (bar) |
| Installation position | vertical |
| Type of shaft seal | mechanical seal |
| Main application areas | Industry and technological processes, Water supply, Building engineering equipment |
| Max. drive power | 7,50 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 2850 (1/min) |
| Backup pump | yes |
| Connection type | direct |
| Operating mode | cascading and variable |
Features
Brand
KSB
