The VEGATOR 141 signal generation device is designed for
level alarms with continuously measuring sensors with output 4 ... 20
mA. The device processes the measured values from the sensor and outputs
the switching signal depends on the set trigger threshold.
The device is used to perform simple control tasks and
management. Typical application is protection against overflow or dry
stroke, as well as level height control. Additionally, there is an exit
the fault signal.
Features
- Easy to set the switching point by means of a potentiometer
- Indication of the switching status by means of an LED
- Easy mounting on a carrier rail, removable coded terminals
Technical data
Entrance:1 x Sensor input 4 ... 20 mA active (Ex and non-Ex) /alternatively 1 x Sensor input 4 ... 20 mA passive (non-Ex)
Exit:1 x Relay Output (SPDT) /Optional 1 x Fault Signal Relay Output (SPDT)
Integration time:installed
Operating voltage:20 … 253 V AC/DC, 50/60 Hz
