Main application areas
- Water
- Water supply
- Irrigation
- Sprinkling irrigation, irrigation
- Water transportation
Overview of technical data
| Q (50Hz) | 0.0 – 3.0 (m³/h) |
| H (50Hz) | 0.0 – 55.0 (m) |
| Type of bearing | ball bearing |
| Drive | electric motor |
| Drive motor frequency | 50 Hz |
| Type of drive | electric motor |
| Electrical connector | 230/400 V, 3~ |
| Max. permissible liquid temperature | 90 (°C) |
| Installation of the unit | "dry" installation |
| Housing type | housing with an annular camera |
| Type of connection | carving |
| Installation position | horizontal |
| Main application areas | Water supply, Engineering equipment of buildings |
| Housing material | grey cast iron |
| Max. working pressure from the pressure sides | 8 (bar) |
| Type of installation | stationary |
Features
Brand
KSB
