Main application areas
- Polluted water
- Equipment for buildings
- Waste water
- Installations for lifting drains
- Installations for lifting polluted waters
- water disposal
Overview of technical data
| Q (50Hz) | 0.0 – 140.0 (m³/h) |
| H (50Hz) | 0.0 – 24.5 (m) |
| Type of bearing | ball bearing |
| Drive motor frequency | 50 Hz |
| Type of drive | electric motor |
| Drive motor voltage | low voltage |
| Impeller material (according to E standard | PP, CHROM-NICKEL-STAHL |
| Type of coupling | directly |
| Type of lubricant | grease |
| Max. permissible liquid temperature | 40 (°C) |
| Max. number of pumps | 2 |
| Installation of the unit | "dry" installations, flooded |
| Suction characteristics | non-self-priming |
| Type of connection | the flange |
| UNSPSC classification | 4015150300 |
| Housing material (according to EN standard) | PP, PE, JL 104 |
| eClass | 36410100, 36410107, 00000000, 36410000 |
| Installation position | horizontal |
| Type of shaft seal | mechanical seal |
| Main application areas | Water supply, wastewater, Building engineering equipment |
| Housing material | artificial material |
| Max. drive power | 11,80 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 2800 (1/min) |
Features
Brand
KSB
