Food grade ball valves
Sanitary ball valves in the transmission of working media
The use of sanitary ball valves in the food and pharmaceutical industries is an indicator that the product is handled with care and delicacy. This applies in particular to viscous products, products with clots, etc.
Design features of ball valves
The design with through channels and no flow restrictions makes ball valves optimal for handling viscous liquids or liquids containing particles. All this is due to the fact that the valve chamber does not experience hydraulic resistance and does not create obstacles for the passage of the product.
According to the design of the shut-off valves, there are:
| With a floating ball | In this case, the ball is not rigidly connected to the spindle, but moves relative to it and, under the influence of the pressure of the medium from the inlet side, presses against the O-ring from the outlet side, thus sealing the valve. |
| With a ball in the supports | In such cranes, the ball is installed and rotated in supports that have an axial protrusion in the lower part, entering a special recess, and the seats are pressed against its spherical surface under pressure. |
Technical parameters and advantages:
- Nominal diameter: DN25~DN100 1"~4"
- Maximum pressure: 10 bar
- Minimum pressure: 8 bar
- Temperature range: -10C~+150C
- Control: Pneumatic or manual
- The absence of non-flushed areas;
- Hygienic seals of the valve body, eliminating backlash;
- Protection from water shocks;
- Use in lines with pigging systems of mechanical cleaning (pigging systems);
- Filling of PTFE cavities;
- Fittings for connecting supply lines of cleaning solutions;
- The heating shirt.
The Salutech company will select high-quality shut-off valves, take into account your wishes. Please contact us!
The ball valve purchased from us will serve you for years without causing complaints. Our ball valves are made of high-quality metal, resistant to aggressive environments.
We offer you ball valves at a price that is significantly lower than the average market price. See for yourself!
Favorable terms of sale, prompt delivery, a discount system for regular customers are our advantages.
Call us, evaluate the advantages of cooperation with our company!
