MICRO 41/3E (MVE 41/3 M) pad vibrator
Standard series of pad vibrators MICRO MVE single-phase with frequency 3000 rpm. This type of pad vibrators provides centrifugal force from 4 to 45 kg. The pad vibrator is ATEX ExII3D and ETL certified, Class II, Division 2 for use in the presence of potentially flammable powders.
| Article number | E200041M |
| Manufacturer | OLI S.P.A |
| Length (mm) | 161 |
| Width (mm) | 110 |
| Height (mm) | 76.5 |
| Gross weight (kg) | 2.4 |
| Power (kW) | 0.05 |
| Connection type | triangle |
| Working torque (kg*cm) | 0.9 |
| Driving force (kG) | 45 |
| Voltage (V) | 230 |
| Current strength (A max) | 0.25 |
Features
Centrifugal force, kN
0,45
Power, kW:
0,06
Rotation speed, rpm
3000
Rated current, A
0,2
Power Supply, In
~ 230V AC
Weight, kg
2,4
Brand
OLI
