Main application areas
- Hydraulic transport for solid materials
- Hydraulic transport for sludge
- Mining
- Disinfection
- Industrial processes
- Process
Overview of technical data
| Q (50Hz) | 25.0 – 2455.0 (m³/h) |
| H (50Hz) | 5.0 – 50.0 (m) |
| Type of bearing | rolling bearing |
| Type of drive | electric motor, turbine , internal combustion engine |
| Type of coupling | directly, gearbox, without, adjustable coupling, counter drive/belt drive, driveshaft, belt drive |
| Type of lubricant | grease/oil lubrication |
| Installation of the unit | "dry" installation, "wet" installation, "dry" installation, flooded |
| Max. free passage | 107 (mm) |
| Type of shaft seal | stuffing box, mechanical seal, hydrodynamic seal |
| Main application areas | Industry and technological processes, Water supply, Wastewater, Energy, Mining /Dredging, Shipping /Shipbuilding |
| Type of installation | portable, stationary |
Features
Brand
KSB
