Main application areas
- Auxiliary Systems
- Nuclear power plants
- Mining
- Oil refinery
- Petrochemical industry
- Oil /Gas
- Cooling water and condensate
- Boiler power supply
- Industry and technological process
- Process
- Pipelines and reservoirs
- Chemistry
- Public power plants
- Energy industry
Overview of technical data
| Q (50Hz) | 0.0 – 4800.0 (m³/h) |
| H (50Hz) | 0.0 – 285.0 (m) |
| Type of bearing | rolling bearing |
| Separation of the body | transverse (radial) |
| Drive motor frequency | 50 Hz /60 Hz |
| Drive motor voltage | low voltage, high voltage |
| Number of impeller inputs | single-threaded |
| Heated | yes |
| Type of installation | base plate |
| Type of coupling | directly |
| Type of lubricant | oil lubrication |
| Max. permissible liquid temperature | 450 (°C) |
| The position of the nozzle | mechanical suction |
| Maximum operating pressure | PN 100 |
| Process execution | yes |
| Installation of the unit | "dry" installation |
| Standard | API 610, ISO 13709 |
| Suction characteristics | non-self-priming |
| Housing type | spiral body |
| Type of impeller | multi-channel impeller, closed, closed/radial, radial |
| Type of connection | the flange |
| UNSPSC classification | 4015150300 |
| eClass | 36410101, 36410000, 36410100 |
| Installation position | horizontal |
| Type of shaft seal | mechanical seal |
| Main application areas | Oil/Gas, Industry and technological processes |
| Max. working pressure from the pressure sides | 110 (bar) |
| Max. drive power | 3200 (kW) |
| Type of installation | stationary |
| Max. rotation speed | 3500 (1/min) |
Features
Brand
KSB
