JUMO AQUIS touch S
Modular multichannel device for analyzing liquid parameters with integrated regulator and recorder
Short description
Measurement
JUMO AQUIS touch S is a centralized display system
and further processing of parameters such as pH, redox potential, electrolyte conductivity, resistance of especially pure water, temperature, concentration of disinfectants such as free chlorine, total chlorine, chlorine dioxide, ozone, hydrogen peroxide and peracetic acid, and consumption. Frequency inputs (counters) are available to measure the flow rate. Universal inputs can be used to measure analog values using a normalized signal [0(4) ...20 mA or 0 ... 10 V]. The device can simultaneously measure and process up to 19 parameters.
Regulation:
In addition to numerous simple alarm functions, boundary values or time-controlled switches, up to 4 control circuits can be set simultaneously in the JUMO AQUIS touch S. In this case, proven JUMO regulation algorithms for P-, PI-, PD- and PID regulation are used
Indication
The 5.5-inch TFT touchscreen serves both to display all parameters and to control and configure the device. The presence of full-text menus minimizes the need to use the operating instructions. By default, the device's menu language can be English, German or French (see ordering information). Using the setup program for PC, the language library can be expanded to 15 languages.
Registration
A recorder is integrated into the device to record data. The screen can display time dependencies for 8 analog measured values and 6 binary ones
signals. The stored data is protected from manipulation and fully meets all the requirements of regulatory authorities. The data can be read using the JUMO PCC program or a USB flash card and processed using the program.
