AC Drive V1000 CIMR VC4A0023FAA

A series of vector inverters V1000 productions Yaskawa It has a high level of performance and is equipped with great functionality for efficient and economical control of asynchronous and synchronous (permanent magnet) AC electric motors. They are suitable for performing both simple and complex production operations, while having a very user-friendly interface and all the tools for quick and easy tincture.

A variety of intelligent functions help to accurately and flexibly adjust the operation of the drive, a visual graphical interface for the operator. The safety system includes the function of safely removing torque from the shaft (category 3, SIL2). The estimated uptime is 10 years.

The small-sized V1000 drives can be comfortably placed even in conditions of limited space, for example, installation in line. All standard sizes have two modes of overload capacity, three types of mains power are presented.

Technical characteristics of Yaskawa V1000 electric drives

• Supply voltage: 1AC 200-240V, 3AC 200-240V, 380 - 480V ;
• Power of electric motors: 0.1 - 18.5 kW;
• Output current: 0.8 -69 A;
• Management methods: scalar, vector sensorless;
• Output frequency: 0.01 - 400 Hz;
• Permissible overloads: the normal mode is 120% of the nom. current for 60 seconds, heavy duty - 150% of nom. current for 60 seconds;
• Enclosure protection class: IP20;
• Interfaces: RS-485/422 MEMOBUS/Modbus, по запросу CANopen, CC-Link, DeviceNet, EtherCAT, Ethernet/IP, MECHATROLINK-II, Modbus TCP /IP, PROFIBUS-DP, PROFINET;
• Visualization and customization tools: LCD display with push-button navigation or panel with LED indication, software for control and parameterization using a personal computer;
• Other features and functions: 17-step speed adjustment, auto-tuning, torque control, attenuation, instantaneous power drop compensation, slip compensation, torque limitation, acceleration/braking curve adjustment, PID controller, energy consumption accounting, auto restart, safe torque shutdown and others.

V1000 I/O Configuration

• Digital: 6 inputs.
• Analog: 2 inputs and 1 output.
• Relay: 1 exit.
• Pulse: 1 exit.
• Optocoupler output.

Optional modules for the V1000 series

• Modules of industrial communication interfaces.
• Anti-interference filters.
• AC and DC chokes.
• Brake resistors and interrupters.
• 24 V power supply unit.
• A block for connecting and copying via USB.
• Control panel with LCD display.
• Control unit with LED indication.
• Cable for remote installation of the remote control, holder.

Parameters of standard sizes of electric drives Yaskawa V1000

supply voltage 200 V, 1 phase

supply voltage 200 V, 3 phases

Supply voltage 400 V, 3 phases

You can buy Yaskawa V1000 frequency converters, find out the price and more information about the products by contacting our specialists.
